3D Powder Mixing Machine Multi Direction Movement Mixer
Product Details:
| Place of Origin: | China |
| Brand Name: | Guojin |
| Certification: | ISO |
| Model Number: | THDM-50 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard export Carton |
| Delivery Time: | 20-30days |
| Supply Ability: | 10 sets per month |
|
Detail Information |
|||
| Item Name: | THDW-50L 3D Powder Mixing Machine Three Dimensional Movement Mixer | Application: | Food Industry,Chemical Industry |
|---|---|---|---|
| Model Type: | THDM-50 | Barrel Volume: | 50L |
| Work Volume(%): | 20-80 | Input Voltage: | 380V 50Hz |
| Power: | 1.1KW | Speed Limit(rpm): | 0-15 |
| Net Weight: | 230KGS | Overall Dimension: | 1200x1100x1050MM |
| Highlight: | 3D Powder Mixing Machine,50L Mixing Machine,10r/min Three Dimensional Mixer |
||
Product Description
THDW-50L 3D Powder Mixing Machine Three Dimensional Movement Mixer
Three dimension mixer. The mixing barrel of the machine moves in multi-direction. For the materials, there is no centrifugal function, without the specification gravity segregation and the layer division. For each of build-up phenomenon, there is the remarkable weight rate. The mixing rate is high. The machine is the desired one of various mixers at present.
1. The machine can perform a very uniform mixing of power or granule materials with a good mobility.
2. Because the mixing tank rotates in multiple directions, there is no centrifugal force acting on the material, as well as no phenomena of gravity segregation, delamination and accumulation of materials so the mixing rate can be up to 99.9%.Therefore, it is an ideal product currently compared with other various mixers.
3. The tank has high loading rate max.80% , so that its mixing efficient is high and short mixing time.
4. The barrel transitional radius everywhere, and also has been polished ,which has achieved GMP quality standards.
Technical Parameters
| Type | THDM-5 | THDM-100 | THDM-200 | THDM-400 | THDM-600 | THDM-800 | THDM-1000 |
| Material barrel volume(L) | 5 | 100 | 200 | 400 | 600 | 800 | 1000 |
| Max loading volume(L) | 4.25 | 85 | 170 | 340 | 510 | 680 | 850 |
| Max loading weight(kg) | 5 | 80 | 150 | 200 | 300 | 400 | 500 |
| Spindle rotation speed(r/min) | 24 | 15 | 12 | 10 | 10 | 10 | 10 |
| Motor power(kw) | 0.37 | 2.2 | 3 | 4 | 5.5 | 7.5 | 11 |
| Overall dimensions(mm) | 600*1000*1000 | 1200*1800*1500 | 1300*1600*1500 | 1500*2200*1500 | 1850*2500*1650 | 1900*2400*2100 | 1950*2500*2400 |
| Weight(kg) | 150 | 500 | 750 | 1200 | 1500 | 1650 | 1800 |
Production Show
