VTM V Type Powder Mixer
Product Details:
| Place of Origin: | China |
| Brand Name: | Guojin |
| Certification: | ISO |
| Model Number: | VTM-0.3 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard export Carton |
| Delivery Time: | 20-30days |
| Supply Ability: | 10 sets per month |
|
Detail Information |
|||
| Item Name: | VTM V Type Powder Mixer | Application: | Medicine Processing, Chemicals Processing, Plastics Processing, Food Processing |
|---|---|---|---|
| Production Capacity: | 120kg/batch | Model Of Vacuum Pump: | W2 |
| Time Of Raw Material Fed In: | 3-5min | Mixing Time: | 6-10min |
| Total Volume: | 0.3M3 | Stirring Speed: | 12r/min |
| Motor Power: | 1.1kw | Rotating Height: | 1760mm |
| Weight: | 320kg | ||
| Highlight: | mixing equipment,blending machine |
||
Product Description
VTM V Type Powder Mixer
This machine is designed for mixing two or more dry powder and granule raw materials from pharmaceutical industry, chemical industry, foodstuff industry and so on. The structure of this machine in unique. The mixing efficiency is high and no dead corner. It is made of stainless steel. The inner and outer wall is processed through polishing. Nice appearance. Mixture uniform. The scope of application is wide. The forced stirrer can also be equipped, according to request of client, to meet the requirements of raw materials that contain pretty fine powder, cake and certain moisture as request.
Product Application
The mixer is used for mixing the dry material grains inmedical, chemical, food, metallurgical and other industries.
Technical Parameters
| Model | 0.18 | 0.3 | 0.5 | 1.0 | 1.5 | 2.0 | 2.5 | 3.0 | 4.0 | 5.0 |
| Productive capacity(kg/batch) | 72 | 120 | 200 | 400 | 1600 | 800 | 1000 | 1200 | 1600 | 2000 |
| Model of vacuum pump | W2 | W2 | W2 | W3 | W3 | W3 | W3 | W4 | W4 | W4 |
| Time of raw material fed in(min) | 3-5 | 3-5 | 4-6 | 6-9 | 6-10 | 8-13 | 8-15 | 8-12 | 10-15 | 15-20 |
| Mixing time(min) | 4-8 | 6-10 | 6-10 | 6-10 | 6-10 | 6-10 | 6-10 | 8-12 | 8-12 | 8-12 |
| Total volume(M3) | 0.18 | 0.3 | 0.5 | 1.0 | 1.5 | 2.0 | 2.5 | 3.0 | 4.0 | 5.0 |
| Stirring speed(r/min) | 12 | 12 | 12 | 12 | 12 | 12 | 12 | 10 | 10 | 10 |
| Motor power(kw) | 1.1 | 1.1 | 2.2 | 4 | 4 | 5 | 7.5 | 7.5 | 11 | 15 |
| Rotating height(mm) | 1580 | 1760 | 2400 | 2840 | 3010 | 3240 | 3680 | 3700 | 4350 | 4800 |
| Weight(kg) | 280 | 320 | 550 | 950 | 1020 | 1600 | 2040 | 2300 | 2800 | 3250 |
