Multifunctional Automatic 500kg Freeze Drying Machine
Product Details:
| Place of Origin: | China |
| Brand Name: | OEM |
| Certification: | CE;ISO |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard export Carton |
| Delivery Time: | 20-30days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10 sets per month |
|
Detail Information |
|||
| Type: | Vacuum Drying Equipment | Drying Capacity (kg): | 500 Kg |
|---|---|---|---|
| Application: | Medicine Processing, Chemicals Processing, Food Processing | Condition: | New |
| Voltage: | Optional | Power(W): | 72kw |
| Dimension(L*W*H): | Customized | Key Selling Points: | Automatic |
| Warranty: | 5 Years | After-sales Service Provided: | Online Support |
| Weight (KG): | 10000 | After Warranty Service: | Online Support |
| Applicable Industries: | Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Retail, Pharmaceutical Industry | Showroom Location: | United States, Pakistan, Colombia |
| Weight: | 10000kgs | Dry Area: | 12.96 Square Meter |
| Tray Dimension: | 1200*1200mm | Power Consumption: | 75kw |
| Shelf Spacing: | 70 Mm | Heating Mode: | Conduction Mode |
| Nominal Area: | 13 Square Meter | Control System: | PLC Control |
| Operation System: | Touch Screen | ||
| Highlight: | 500kg Freeze Drying Machine,Multifunctional Freeze Drying Machine,500kg freeze drying equipment |
||
Product Description
Multifunctional Automatic 500kg Freeze Drying Machine
Product Description
Freeze-dry (brief named Freeze-dry) is a stable process of material dried which will put the material contained with wate to freeze to solid first,then make among them of the wate rsublimate from solid to air condition,removing water to preserve materials Products at solution stage ar efrozen through sublimation and desorption,then the solvent reduce to a certain extent,there by preventing the for mation of micro-organisms or chemical reaction between the solute and solvent that products can be preserved for along time and maintained its nature. Vacuum freeze-drying method is a liquid→solid→gaseous process.In freeze-drying process,"liquid bridge"between the solution part icles has been frozen into"solid bridge".There lative position of particles has been fixed and does not exist surface tensionongas-liquid inter face between the two particles.With the continuous distillation o fsolvent,"solid bridge"continuously decrease,but the there lative position between two particles will not longer change until the "solid bridge"completely disappear.
Machine Data
| Vacuum Freeze Drying Machine | |
| public distribution | |
| Power(three-phase and five-wire system) | 380V/50HZ |
| Power consumption | 72Kw |
| Cooling water qty | ≥20m3/h(T≤30℃/P=0.15-0.2Mpa ) |
| Compressed air | ≥0.1m3/Min(P=0.5-0.8Mpa) |
| Clean water | ≥100L/Min (T=80℃/P≥0.4-0.5Mpa) |
| Whole volume | (According to design standard) |
| Structure | Integral(Rectangularboxdry +Rectangularcoldtrap) |
| Total weight | ≈10000kg |
Q: What price terms you offer?
A: We can offer FOB, FCA, CFR, CIF, EXW and other price terms based on your request.
Q: What payment terms you take?
A: TT, LC, other terms are also workable.
Q: Will you help with installation and stuff training?
A: Yes, we can send our engineers to your place to guide the installation and train your workers if you need, but the buyer should bear our technician's round tickets, accomodation, food and subsidiary USD100/day.
A: We can offer FOB, FCA, CFR, CIF, EXW and other price terms based on your request.
Q: What payment terms you take?
A: TT, LC, other terms are also workable.
Q: Will you help with installation and stuff training?
A: Yes, we can send our engineers to your place to guide the installation and train your workers if you need, but the buyer should bear our technician's round tickets, accomodation, food and subsidiary USD100/day.
Want to Know more details about this product
