Energy Saving Industrial Coal Rotary Drying Machine
Product Details:
| Place of Origin: | China |
| Brand Name: | OEM |
| Certification: | CE;ISO |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard export Carton |
| Delivery Time: | 20-30days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10 sets per month |
|
Detail Information |
|||
| Type: | Rotary Drying Equipment | Application: | Chemicals Processing, Cement, Coal, Wood, Sand, Ore, Sawdust, Compound Fertilizer |
|---|---|---|---|
| Condition: | New | Voltage: | 220-380V |
| Power(W): | 5-160kw | Dimension(L*W*H): | Depending On Model |
| Key Selling Points: | Energy Saving | Warranty: | 1 YEAR |
| After-sales Service Provided: | Online Support, Video Technical Support, Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Engineers Available To Service Machinery Overseas | Applicable Industries: | Energy & Mining |
| Color: | Customizable | Product Name: | Coal Drying Machine |
| Weight: | 5-80t | ||
| Highlight: | Coal Rotary Drying Machine,Energy Saving Rotary Drying Machine,160kw Rotary Sand Dryer |
||
Product Description
Energy Saving Industrial Coal Rotary Drying Machine
Product Introduction
The Rotary Dryer is widely used in the field of building materials, metallurgies, chemical industry, cement and so on. It can dry slag, coal powder, mining powder, clay, sand, limestone, compound fertilizer, sawdust and so on. It is made up of rotary body, liting blade, driving device, supporting device etc. The dryer has advantages of reasonable structure, high efficiency, low energy consumption and convenient for transportation.
Working Principle
Rotary dryers consist of a horizontally inclined rotating cylinder. Material is fed at one end and discharged at the other end. In direct-type rotary dryers, hot gases move through the cylinder in direct contact with the material, either with or against the direction of its flow. The cylinder is equipped with fights, which lift the material and shower it down through the hot gas stream.
Features and Advantages
1. The intermal adopts assembled structure which has improved the accuracy of the equipment and it is easy to transport and install.
2 According to the characteristics of different fertilizers ,we have arranged the second granulation zone reasonably so as to improve the granulation effect.
3. Adopts assembled hoist board so as to exchange heat fully and lower the energy consumption.
4. Temperature induction monitor ,uniform vibration and airproof setting , which improve performance and productivity efficiently .
5. The assorted combustion furmace is a type of energy-efficient and has the characteristics of smaller area ,easy regulation and equipped with greenhouse
Specification
| Speafication (m) | Shel Cubage (m3) | Capacity (t/h) | Instlltion Obliquity (%) | Highest Inlet Air Temperature (C) | Power (kv) | Weight (t) |
| φ1.2x10 | 11.3 | 2.4~3.0 | 3~5 | 700~800 | 7.5 | 11.0 |
| φ1.5*12 | 21.2 | 4.5~5.7 | 3~5 | 700~800 | 15.0 | 18.5 |
| φ1.5*15 | 26.5 | 5.7~7.1 | 3~5 | 700~800 | 15.0 | 20.5 |
| φ1.8x12 | 30.5 | 6.5~8.1 | 3~5 | 700~800 | 18.5 | 21.5 |
| φ2.2*12 | 45.6 | 9.7~12.2 | 3~5 | 700~800 | 22.0 | 33.5 |
| φ2.2x14 | 53.2 | 11.4~14.2 | 3~5 | 700~800 | 22.0 | 36.0 |
| φ2.2*16 | 60.8 | 13.0~16.2 | 3~5 | 700~800 | 22.0 | 38.0 |
| φ2.4*14 | 63.3 | 13.5~16.9 | 3~5 | 700~800 | 37.0 | 45.0 |
| φ2.4*18 | 81.4 | 17.4~21.7 | 3~5 | 700~800 | 37.0 | 49.0 |
| φ2.4*20 | 90.4 | 19.3~24.1 | 3~5 | 700~800 | 45.0 | 54.0 |
| φ2.4*22 | 99.5 | 21.2~26.5 | 3~5 | 700~800 | 45.0 | 58.0 |
| φ2.6* 24 | 127.4 | 27.2~34.0 | 3~5 | 700~800 | 55 | 73.0 |
| φ3.0*20 | 141.3 | 30.1~37.7 | 3~5 | 700~800 | 75 | 85.0 |
| φ3.0*25 | 176.6 | 37.7~47.1 | 3~5 | 700~800 | 75 | 95.0 |
| φ3.2*25 | 201 | 42.9~53.6 | 3~5 | 700~800 | 90 | 110.0 |
| φ3.6* 28 | 285 | 60.8~76.0 | 3~5 | 700~800 | 160 | 135.0 |
