Milk Powder Automatic Industrial Spray Dryer Granulator
Product Details:
| Place of Origin: | Spray Drying Series |
| Brand Name: | OEM |
| Certification: | CE;ISO |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard export Carton |
| Delivery Time: | 20-30days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10 sets per month |
|
Detail Information |
|||
| Type: | Spray Drying Machine | Electric Power: | 150 Kw |
|---|---|---|---|
| Heat Source: | Steam Pius Electricity | Temperature Of Air Inlet: | 150-200 ℃ |
| Temperature Of Air Outlet: | 80-100 ℃ | Moisture Content Of Finished Prodct: | 3%-5% |
| Condition: | New | Material: | Stainless Steel |
| Installation: | Under Technician's Guidance | Spray System: | Centrifugal Nozzle |
| Highlight: | Industrial Spray Dryer Granulator,Automatic Spray Dryer Granulator,Milk Powder Spray Dryer Granulator |
||
Product Description
Milk Powder Automatic Industrial Spray Dryer Granulator
Technical Parameters:
| Spec | ZPG-10 | ZPG-50 | ZPG-100 | ZPG-200 | ZPG-300 |
| Evaporation Capacity (kg / h) | 10 | 50 | 100 | 200 | 300 |
| Moisture Content of Finished Prodct | 3%-5% | ||||
| Electric Power (kw) | 45 | 100 | 150 | 250 | 330 |
| Temperature of Air Inlet | 150℃ -200℃ | ||||
| Temperature of Air Outlet | 80℃-100℃ | ||||
| Collecting Method of Product and its Efficiency | II grade cyclone or I grade cyclone and I grade web-method dedusted of 95% | ||||
Descriptions:
The spray dryer is one of the continuous atmospheric dryers. The liquid material is sprayed with a special device to form a mist, and is dried in contact with hot air. For the drying of some heat-sensitive liquids, suspensions and viscous liquids, such as milk, eggs, tannins and drugs. Also used for drying fuels, intermediates, soap powder and inorganic salts.
Features:
1. Tower body has jacket of air.
2. Tower body is equipped with automatic vibration and beating device.
3. Tower body and pipe line have cleaning hole and sewage discharge hole that can open quickly.
4. Thermostat ending tank.
5. Accompanied parts of high pressure washing tower.
6. The parts that can contact with raw material are made of stainless steel fully.
7. The collecting of raw material adapts two grade cyclone duster or one-grade cyclone duster and one-grade damp duster.
8. The temperature of inlet air can be controlled automatically and continuously.
9. Equipped with air sweeping device.
