Stainless Steel Chemical 1000kg/h Industrial Spray Dryer
Product Details:
| Place of Origin: | China |
| Brand Name: | OEM |
| Certification: | CE;ISO |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard export Carton |
| Delivery Time: | 20-30days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10 sets per month |
|
Detail Information |
|||
| Product Name: | Pressure Spray Dryer | Application: | Indoor |
|---|---|---|---|
| Raw Material: | Stainless Steel 304/316L | Feeding: | Powder |
| Polish: | Drawbench/mirror | Feature: | Automatic, Touch Screen,(explosionproof) |
| Standard: | CE/GMP/BV | Type: | Normal/Unnormal |
| Highlight: | 1000kg/h Industrial Spray Dryer,Chemical Industrial Spray Dryer,1000kg/h Spraying Drying Equipment |
||
Product Description
Stainless Steel Chemical 1000kg/H Industrial Spray Dryer
Descriptions:
The material is sprayed into fine mist by nozzle on the top of tower. Follow the heat wind, the material is dried. The machine's characteristic is high collection rate, no stick onto the wall, energy saving, high efficiency, especially applicable for heat sensitive material. It's widely used in food, dyestuff, chemical industry and so on.
Features:
The dry speed is fast.The surface area of raw material liquid after being atomized will be increased greatly.95%-98% of moisture can be evaporated at moment.The time to finish dry needs about ten seconds to several tens of seconds.It is suitable for drying thermal sensitive material particularly.
The finished produce is ball granule with uniform size.Its fluidity and solubility are good.The purity of product is high and its quality is good.
It scope of application is wide.According to the characteristaltic of raw material,it can use hot air to dry and can also use cool air to granulate.It has strong adaptability to raw material.
Its operation is simple and stable and its control is simple and convienient and is easy to realize automatic operation.
Applications:
Food Industry:fatty milk powder,protein,cocona milk powder,substitute milk powder,egg white(yolk),food and plant,oats,chicken juice,coffee,instant dissoluble tea,seasoning meat,protein,soybean,peanut protein,hydrolysate and so forth.Sugar,corn syrup,corn starch,glucose,pectin,malt suagr,sorbic acid potassium and etc.
Medicine:Traditional Chinese medicine extract,ointment,yeast,vitamin,antibiotic,amylase,lipase and etc.
Plastics and resin:AB,ABS emulsion,uric acid resin,phenolic aldehyde resin,urea-formaldehyde resin,formaldenhyde resin,polythene,poly-chlor-oprene and etc.
Detergent:Common washing powder,advanced washing powder,soap powder,soda ash,emulsifier,brightening agent,orthophosphoric acid and etc.
Chemical Industry:Sodium fluoride(potassium),alkaline dyestuff and pigment,dyestuff intermediate,compound fertilizer,formic silicic acid,catalyst,sulphuric acid agent,amino acid,white carbon and so on.
Ceramic:aluminium oxide,ceramic tile material,magnesium oxide,talcum and so on.
Other:Calmogastrin,hime chloride,stearic acid agent and the cooling spray.
Technical Parameters:
| spec | 50 | 100 | 150 | 200 | 300 | 500 | 1000 |
| Water evaporation capacity Kg/h | 50 | 100 | 150 | 200 | 300 | 500 | 1000 |
| Overall dimension(ф*H) mm | 1600×8900 | 2000×11500 | 2400×13500 | 2800×14800 | 3200×15400 | 3800×18800 | 4600×22500 |
| High-pressure pump pressure Mpa | 2-10 | ||||||
| Power Kw | 8.5 | 14 | 22 | 24 | 30 | 82 | 30 |
| Inlet air temperature ℃ | 300-350 | ||||||
| product water contents % | less than 5 percent, and 5 percent can be achieved. | ||||||
| collection rate % | >97 | ||||||
| electric heater Kw | 75 | 120 | 150 | When the temperature is lower then 200, the parameters should be calculated according to the practical condition. | |||
| electricity + steam Mpa+Kw | 0.5+54 | 0.6+90 | 0.6+108 | ||||
| hot air furnace Kcal/h | 100000 | 150000 | 200000 | 300000 | 400000 | 500000 | 1200000 |
